HW Supplementary Cutter
Suitable for window cutters IV68, IV78 and IV90 Continue
excl. HST , without shipping costs
incl. % VAT , without shipping costs
Description
Supplementary set for wood-aluminium windows Eurofalz IV 68/78/90. Steel, burnished surface.
Suitable for:
FELDER ® window sets 04.1.310 (IV68), 04.2.310 (IV78), 04.2.316 (IV90).
Quality of the cutting edges
HW = tungsten carbide (old designation HM)
HS = high-alloy high-speed steel (high-performance steel)
SP = alloy tool steel (special steel)
Abbreviations
WM = Reversible knife (can be used on both sides)
PM = Profile knife
Technical information
Bore Diameter [mm] | 40 |
Cutter Quality | HW |
Diameter [mm] | 160 |
Execution | IV68, IV78 and IV90 wood-aluminium windows |
Moulding Tool Set Heigth [mm] | 131.4 |
Downloads
- Technical Drawing (PDF | 2.32 MB)
- Calculation (XLS | 45.57 KB)
