Description
This machine will provide you with a higher level of precision and quality than you would ever expect from a planer.For decades the Felder system with double sided disposable planer knifes proved its advantages. Precisely manufactured and adjusted at the factory, there is no need to adjust the planer knives after installation. And no expensive adjustment tools are required!
It’s mere child’s play to change the planer knives. In less than a few minutes you can change either the 4-knife cutterblock.
Felder planer knives are set and ready to use!
With “Power-Drive”
Turn the control switch for quick adjustment; push the button for fine adjustment. The LED display clearly shows the actual value.
... with “Digi-Drive” just type it in
Enter required dimension, press start and the planer table will move accurately to the required position. Required and actual values are shown on LED displays. Additional optional functions, such as incremental position and four programmable thicknesser table positions are available.
Highlights & Details
Adjustable integrated bed rollersOptional integrated adjustable bed rollers are available for processing workpieces with high resin or moisture content.
Trapezoid threaded spindle4 Spindles with trapezoidal threads guarantee precise adjustment and allow the heaviest loads on the planer table. The table height adjustment guideways
(A + B) also stabilize the table against lateral movement particularly in the outfeed direction.
Sectional pressure barA recommended option when planing with a small depth of cut, with very thin workpieces or workpieces with different thicknesses.
Dust extraction hoodHeavy chip loads and moist wood are no problem for the chip extraction hood due to its efficient design and large dimension. 2 spring loaded pressure bars prevent chattering of very thin workpieces during planing.
Table ExtensionsWhen thicknessing several workpieces at once, the 570 mm long table extension with workpiece roller situated on the outfeed is of particular importance, making it easier to remove them once thicknessed.
Height-adjustable scissor tableAn optional 45 ¼” (1150 mm) height adjustable scissor table is available.
Power-DriveThe fully electrical “Power-Drive” planer table control offers the most precise adjustment and repeat accuracy. With a twist of the knob, you can quickly adjust the planing height, then fine-adjust using the button. An integrated LED-display displays the actual value.
Digi-DriveEnter required dimension, press start and the planer table will move accurately to the required position. Required and actual values are shown on LED displays. Additional optional functions, such as incremental position and four programmable thicknesser table positions are available.
Perfect technology2 spring loaded pressure bars prevent chattering of very thin workpieces during planing.
Continuous speedsRegardless of the type of wood and grain, the variable feed speed of between 4–16 m/min always guarantees a perfect planing result.
Cast iron bearing seatsThe solid cast iron cutter-block housing is built for heavy duty work.
We can also provide rubber outfeed rollers as an option.
The pressure beams combined with the rubber or segmented infeed roller serves to machine simultaneously workpieces of differing width.
FELDER cutterblock systemThe Felder system cutterblock has guaranteed perfect planing results for decades.
Resin free locking screws and the self-setting knives make it possible to change the blade in less than 2 minutes. Time consuming adjustments and purchasing of expensive setting gauges are a thing of the past.
Change the blades in record timeQuick and effortless knife change
Self aligning knives are perfectly set each and every time!
No resin buildup on the clamping screws
Extremely quiet operation due to the enclosed design
Standard or Tersa knife systems are also offered
Cost savings due to the 2 or 4 sided time saving cost efficient knives
Silent-Power®
Exclusive for planer/thicknessers from the Felder Group. The Silent-Power® spiral cutterblock reduces noise emissions by more than half when planing. The continuous pulling cut ensures tear-free results when planing all types of wood. With this revolutionary new development from Format4 you are obtaining all of the advantages of a spiral cutterblock at considerably lower operating, investment and adjustment costs. The advantages of the Silent-Power® cutterblock at a glance ...
- Extremely quiet, noise is reduced by half
- Usable blade life twenty times longer than standard blades
- Four highly precise cutting edges on each knife
- Optimised chip extraction and reduced chip volume
- Tear-free jointing results
- Reduced power consumption when compared to similar systems
