Window Cutter Set IV90
consisting of 03.2.316, 04.2.311, 04.2.318 and 401-276 Continue
excl. VAT , without shipping costs
incl. 20% VAT , without shipping costs
Description
Window cutter set with Euro rebate, energy standard EnEV 2009
Countered window frame and casement corner joints, diameter and height adjusted, including set of shims for fine adjustment. Steel moulding tool, bronzed surface. For manual feed, chip thickness limited, low kickback.
Contains moulding tools for
Counter profile of window casements
Counter profile on window frame
Inner profile window casement
Inner profile window frame side and top
Window frame bottom profile
Window casement outer profile
Left centre rebate for double casement windows
Quality of the cutting edges
HW = tungsten carbide (old designation HM)
HS = high-alloy high-speed steel (high-performance steel)
SP = alloy tool steel (special steel)
Abbreviations
WM = Reversible knife (can be used on both sides)
PM = Profile knife
Technical information
Bore Diameter [mm] | 40 |
Cutter Quality | HW |
Execution | for IV90 window |
Downloads
- Technical Drawing (PDF | 1.99 MB)
- Technical Drawing (PDF | 162.09 KB)
- Calculation (XLS | 121.86 KB)
Set includes
HW Window Cutter
04.2.316 | for the production of IV90 windows
A perfect window in just 7 steps!
continue readingHW Glass Bead Cutter
04.2.318 | for Felder window set IV90
Steel glass bead cutter for Felder window set IV90
